AhnLab TrusGuard DPX
Optimum choice for large-scale, hybrid and advanced DDoS attacks
AhnLab TrusGuard DPX is the most powerful protection solution for Anti-DDoS. No.1 Market share in Korea is AhnLab TrusGuard DPX.
Source: “South Korea Distributed Denial of Service (DDoS) Solution Market, Forecast to 2021” August 2017, Frost & Sullivan
AhnLab TrusGuard DPX 의 운영관리 UI 소개 4. AhnLab TrusGuard DPX Specifications. DDoS 공격의 동향과 지속적인. TrusGuard DPX AhnLab TrusGuard DPX는 안랩의 특별한 DDoS 방어 프로세스로 DDoS 공격 패러다임의 변화에 종합적으로 대응합니다. 서비스 운영을 마비시키는 DDoS(Distributed Denial Of Service)공격은 점차 금. AhnLab 보안 제품과 서비스 구성을 한.
Distributed-denial-of-service (DDoS) attacks have become one of the most serious threats against today's Internet-based entities, including e-commerce, infrastructure, and government websites. In a DDoS attack, compromised zombie computers or botnets can take down websites or other Internet services with excessive requests for system resources.
AhnLab TrusGuard DPX is designed to defeat today’s highly complex and sophisticated DDoS attacks with an intelligent defense strategy. It ensures business continuity and resource availability with an all-inclusive security layer that not only detects today’s more complex attacks, but also mitigates their effects.
AhnLab TrusGuard DPX provides all-inclusive features to block these complex attacks, regardless of techniques or methods.
- - Real-time traffic monitoring and automatic self-learning
- - Protection from network to application (HTTP)
- - Source IP based protection and spoofed IP protection including TCP Flooding and others
- - TCP session based protection including TCP Multi-Connection, TCP Established Attack, Low Bandwidth TCP Session Flooding
- - HTTP based protection including HTTP Get Flooding, HTTP Null Page Flooding, HTTP CC Attack, HTTP Redirect Bypass Flooding, SQL Query Based HTTP Attack
- - Protection against new and advanced attacks, like DNS Amplification Attack, RUDY or Slowloris
Multi-Layered Mitigation Filtering
Ahnlab Trusguard Dpx 6000a Ammo
Ahnlab Trusguard Dpx 6000a Systems
AhnLab TrusGuard DPX employs following multi-layered mitigation filters to stop highly complex attacks: Untrusted traffic block, Ant-spoofing protection, HTTP access authentication, Unauthorized IP block, Threshold-based protection and Signature-based protection.
Flexible Deployment – Inline & Out-of-Path
AhnLab TrusGuard DPX can be deployed inline on a network or as part of an out-of-path topology. By allowing traffic bypasses, TrusGuard DPX provides a safe level of fault tolerance and continues to route traffic, even in the event of a system failure. In addition, TrusGuard DPX ensures fault tolerance and operational stability without affecting the traffic flow when located outside of the network path.
Clustering Capability
The outstanding scalability provided by the clustering capability can simultaneously manage up to 120 Gbps of bandwidth and synchronize a list of trusted IP addresses with all the other devices within the cluster.
1 Appliance – 328 Zones (Multi – Tenancy)
AhnLab TrusGuard DPX can simultaneously configure up to 328 different zones with different protection policies for each zone.
Powerful Monitoring
Monitoring traffic flow and mitigation measures across the network is made simple with color indicators: green means the network is secure, orange requires attention, and red is critical. Mobile devices are also supported.
AhnLab TrusGuard DPX Specifications
| TrusGuard DPX 6000A | |
|---|---|
| Throughput | 10G |
| CPU | 6 Core |
| RAM | 64GB |
| CFast | 8GB |
| Console | 1 (RJ-45) |
| 1GC | 10 (Max 34 ports, Including Mgmt) |
| 1GF | 2 (Max 16 ports) |
| 10GF | 0 (Max 16 ports) |
| Bypass | Support |
| Power | 550W Redundant |
| TrusGuard DPX 10000A | |
|---|---|
| Throughput | 40G |
| CPU | 28 Core |
| RAM | 64GB |
| CFast | 8GB |
| Console | 1 (RJ-45) |
| 1GC | 2 (Max 34 ports Including Mgmt) |
| 1GF | 0 (Max 16 ports) |
| 10GF | 4 (Max 16 ports) |
| Bypass | Support |
| Power | 550W Redundant |
